Roof PV mountings are special brackets designed for placing, installing and fixing solar panels in solar PV power systems. Generally, the materials available are aluminium, carbon steel and stainless steel. In the specific installation process, the appropriate installation method needs to be chosen according to the different types of roof. 1. Concrete Roofs The installation of solar mounting systems on concrete roofs all use concrete as the foundation. There are two ways of producing foundations, as follows: ①. Pour Cement on Site to Make Foundations Advantages: it can be integrated into the roof, which can be strong and use less cement. Disadvantages: The rebar needs to be pre-built in the roof of the building. Or use expansion screws to connect the concrete foundation to the roof as one. This tends to damage the waterproof layer of the roof and can easily leak over time. ②. Cement Foundation Counterweight Briquettes Accurate statistics are required on the average annual wind speed at the project site and the wind direction in different seasons to calculate the positive and negative wind pressures. The weight of the concrete foundation is then converted from the wind pressure level. Pre-processed cement briquettes of uniform dimensions are then transported to the site for installation. 2. Mental Roofs Mental roofs are generally used on light steel buildings, mostly in standardized workshops and warehouses. Light steel buildings use light weight coloured steel tiles for the roof so spans can be made very large. This is ideal for the large-scale laying of solar modules. The city's industrial parks are standardized plants built in successive blocks, with large numbers and areas, often allowing the construction of tens of megawatts of solar power plants at a time. The mental roofs are made up of thin metal sheets wrapped in foam sheets, which cannot be used to fix the mountings for the battery components by conventional methods. A special 'clamp' is required, the use of which will not damage the original structure and will not cause leaks or structural damage to the roof as a whole. From a load-bearing point of view: it is inevitable that more brackets will be used if installed at the optimum angle. This will add weight to the roof. From a safety point of view, the modules cannot be installed parallel to the roof by installing at the optimum angle of inclination. This creates additional wind pressure when the wind is blowing, which can be a safety hazard. In summary of the above two points, the modules can only be laid flat on a mental roof. The number of modules installed is only relevant for roof area and load bearing and is not optimized. 3. Glazed Tile Roof This refers to pitched roofs with concrete underneath the tiled surface. The installation is usually done by uncovering the tiles, placing expansion screws in the concrete, installing bent hook adapters and then covering the tiles back up. The key is to control the position of the expansion s...

April 12-14 in Daegu, the 20th International Green Energy Expo — Korea's largest, three Asian and ten world's largest exhibition of renewable technologies successfully drew a large number of visitors eager to explore advanced renewable energy solutions. Kseng Solar exhibited the expo with its vast range of solar racking solutions, covering roof-mount, ground-mount, etc, and our team of experts spoke with numerous interested visitors, who were impressed by the quality and reliability of our products. Presented Products -      Solar Roof Mounting Solutions: Large gap roof mounting systems, Standing Seam Roof Mounting Systems, Triangle Flat Roof Mounting Systems -      Solar Ground Mounting Solutions: Steel Ground Mounting System, Aluminum Ground Mounting System According to Wood Mackenzie, South Korea has set an ambitious target of installing 34GW of solar power by 2030 as part of its basic electricity supply plan. As one of the leading suppliers of solar mounting solutions in the country, Kseng Solar has years of field-proven experience in South Korea, and its efficient and high-quality solar mounting solutions have been greatly favored by local clients, making Kseng Solar a trusted partner in the country's journey push towards a carbon zero future. Dedicated to providing solar racking and tracking systems since 2015 and driven by the mission of “Empowering our world with clean energy”, Kseng Solar will continue to provide more advanced and powerful solar racking solutions and build a stronger local team, helping to create a sustainable future and build a greener Korea.

PV mounting system has a variety of classification methods, such as welding type and assembly type according to the connection method, fixed type and daily type according to the installation structure, and ground type and roof type according to the installation location. No matter what kind of photovoltaic system, the structure of its bracket is generally similar, including connectors, columns, keels, beams, auxiliary parts and other parts. Fixed roof PV mounting system Fixed roof PV mounting system, as the name suggests, refers to a mounting system that keeps its orientation and angle unchanged after installation. The fixed installation method directly places the solar photovoltaic modules towards the low-latitude area (at a certain angle to the ground), and forms a solar photovoltaic array in a series-parallel manner, so as to achieve the purpose of solar photovoltaic power generation. There are many kinds of fixing methods, such as the pile foundation method (direct embedment method), concrete block counterweight method, pre-embedded method, ground anchor method, etc., and the roof fixing method has different schemes depending on the roofing material. . For different roofing materials, there will be different photovoltaic support systems: 1）Glazed tile roof PV mounting system As shown in Figure 1, glazed tiles are construction materials made of soft and hard materials such as alkaline earth and purple sand after extrusion, plastic pressing, and firing. The material is brittle and has poor load-bearing capacity. Picture 1 When installing the bracket, a specially designed main support member is usually fixed to the lower roof of the glazed tile to support the main beam and beam of the bracket. The support members such as the connecting plate are usually designed with multiple openings as shown in Figure 2, which is flexible and effective. Bracket position adjustment. Aluminum alloy pressing blocks are used for crimping between components and beams. Picture 2 2）Metal roof mounting system Metal plate is a steel formed by cold pressing or cold rolling of thin steel plate. The steel plate adopts organic coated thin steel plate (or color steel plate), galvanized thin steel plate, anti-corrosion thin steel plate (asbestos-containing asphalt layer) or other thin steel plates. Profiled steel plate has the advantages of light unit weight, high strength, good seismic performance, fast construction, beautiful appearance, etc. It is a good building material and component, mainly used for enclosure structures, floors, and other structures. Metal roof are generally divided into: upright seam type, bite type (corner type) type, buckle type (concealed type) type, and fastener connection (nail type) type. Picture 3 When installing a photovoltaic system on a metal roof, the shape and load-bearing capacity of the metal roof should be fully considered to determine the fixing method of the bracket. The fixing method of the matel roof bracket is mainly determined acc...

Roofs around the world can be broadly divided into domestic glazed tile roofs, concrete flat roofs and mental roofs. For the installation of rooftop solar power plants, "waterproofing" has to be considered a very important factor! The general principle of roof waterproofing is that it is better to guide than to block, i.e. in case of heavy rainfall, ensure that the nodes can be treated smoothly so that the water cascades off and the roof does not leak. Waterproofing of PV Mounting for Concrete Flat Roofs For new buildings with concrete flat roofs or villa concrete sloping roofs (covered with tiles), the bolts should usually be pre-built at the time of design and the roof waterproofed in accordance with conventional practice. For both types of existing buildings mentioned above, the roof structure should be identified first. When connecting the PV module base to the structural layer, the perimeter of the metal embed parts at the top of the base is the weak point for waterproofing. If not handled properly, rainwater can easily seep down into the structural layer from around the bolts of the buried parts, causing corrosion to the structural layer's reinforcing steel and creating a safety hazard. Waterproofing of PV Mounting Installation for Mental Roofs For mental roofs, the steel structure of the PV mounting system needs to penetrate the original waterproofing layer and the pressed steel sheets and be fixed to the main steel structure of the building. Then refer to the mental roof waterproofing practice for vapour barrier, insulation and waterproofing treatment. The focus of construction is on removing rust and corrosion, sealing, and applying a waterproofing coating to the substrate and periphery. For local leaks in mental roofs, a high quality neutral weather resistant sealant should be used to apply and seal them. For colour plates with severe localized corrosion, they need to be replaced before installing the PV modules. 1)For cases of colour steel plates with trapezoidal rib sections: The PV Mounting is usually connected to the colour steel plate from the side face or top side by means of self-tapping bolts. Self-tapping bolts must be supplied with matching weather-sealed waterproof gaskets. And after fixing the self-tapping bolts, the screws shall be coated with a high quality neutral weatherproof sealant. 2)For cases with cable sleeves through roof panels: Practices are available on existing national standard drawing sets. They can be used in design and construction to suit the actual project. 3)For cases with cables through roof panels: Waterproofing can be carried out using Dektite Cover. It is a roof waterproofing structure, often used in the presence of coloured pressed steel roofs, with good physical properties and chemical resistance to overcome problems such as leakage of rigid waterproofing materials. Waterproofing of the Roof Perforations Made by the Mounting Manufacturer For existing buildings with concrete flat roofs or villa conc...

In order to obtain maximum economic benefits for an ideal tracking photovoltaic power station, in addition to the technical breakthrough of panel direction, the Angle adjustment of photovoltaic support is also an important direction to increase energy efficiency. The photovoltaic panel can adjust the Angle to follow the sun, increase the direct light surface and effectively improve the power generation. The tracking photovoltaic bracket comes into being. The current photovoltaic market is mainly composed of three parts: structure, control and drive. The control system monitors the Angle of the module through the sensor and instructs the support to drive the photovoltaic module for tracking. Let's talk today One word tracking the core of photovoltaic support system operation - control system. #01  Tracking program Photovoltaic industry forefront tracking controller manufacturers have gradually begun to use AI autonomous learning algorithm and astronomical algorithm to optimize tracking Angle and improve power generation. In order to build an intelligent and efficient tracking photovoltaic power station, Kseng's tracking control program meets OTA remote firmware upgrade, and implanting AI autonomous learning algorithm and astronomical algorithm, comprehensively upgrading tracking hardware and software, effectively improving tracking accuracy and intelligently increasing power generation 10-25%. #02 Tracking mode Sensors in the tracking system are responsible for monitoring signals, not limited to light, wind, rain, snow and other sensors. It will monitor information over the wireless The communication is transmitted to the control box for program decision, and the tracking mode is switched intelligently. A tilt sensor is set in the KSeng tracking control box for angle determination, and the motor is driven to make the bracket conform to the target Angle. When the wind speed sensor senses the maximum wind speed, or even bad weather such as heavy rain and snow, the controller will drive the bracket into the protection angle, so as to protect the whole bracket and optimize the reliability and safety of the system. #03 Debugging tool The on-site installation, operation and maintenance of photovoltaic power stations usually use software to debug the on-site support system. Kseng has a variety of modes, such as the interactive interface on the device, mobile APP, upper computer, Web and debugging tools, to carry out power station operation and maintenance work, meet the one-to-one, one-to-many centralized management to achieve remote operation and maintenance of each tracking controller. Diversified operation and maintenance. The model can better serve the complex construction site environment and effectively improve the working efficiency of the power station. #04 SCADA Backstage First of all, Kseng provides convenient SCADA background operating system which can monitor different block areas, each subarray and each heel in real time, each tracker t...

March 2023, Kseng Solar has significantly expanded its market presence by participating in four major renewable energy expo across Europe, including Energiesparmesse Wels 2023 in Austria, Solar Solutions International in the Netherlands, BePOSITIVE 2023 in France, and K.EY - The Energy Transition Expo in Italy. With advanced technical innovations and easy-to-use features, the top-notch solar racking solutions of Kseng Solar draw huge attention from local clients. Presented Products - Solar Roof Mounting Solutions: Universal rapid solar mounting systems, L feet Solar Metal Roof Mounting Systems, Standing Seam Roof Mounting Systems, Ballast Roof Mounting Systems - Easy Solar Bracket: Universal Easy Solar Bracket, Balcony Easy Solar Bracket - Solar Ground Mounting Solutions: Aluminum Ground Mounting System, Steel Ground Mounting System Currently, the European Union(EU) is on course to exceed its renewable power target, aiming to increase the share of renewable energy to 40% by 2030. EU has made relevant policies to facilitate the rapid expansion of photovoltaics, and Kseng Solar is glad to help realize the energy transition in the future with a comprehensive solar racking portfolio. Dedicated to providing solar racking and tracking systems since 2015 and driven by the mission of “Empowering our world with clean energy”, Kseng Solar will continue to deliver more cutting-edge solar racking solutions to enable households, businesses, and communities in Europe to benefit from sustainable energy.
